GC 363 Combined detector for activating and protecting automatic sliding doors with ten different infrared light curtain configuration settings
- Radar movement detector with infrared light curtain and third presence detector
- Reliable detection up to an installation height of 3500 mm.
- Ten adjustable light curtain configurations without additional light prisms
- Fewer total sensors are required due to the large detection area on the floor
- Movement direction detection and cross-traffic fade-out help save energy
- All settings can be changed via remote control
- Reduced installation work needed due to the combination of activation and protection in a single device
Combined detector for activating and protecting automatic sliding doors with ten different infrared light curtain configuration settings
Application Areas
- Activation and protection of automatic sliding doors
- Interior and exterior doors
- Complicated flooring, such as reflective floors, entrance mats, metal rails
- Wall, ceiling, or integrated ceiling installation
Installation situations in reference objects and videos
Automatic sliding door Powerdrive PL EI30, Athletics center Oym, Switzerland
Automatic sliding door system for fire protection doors with resistance class EI30 © Lorenz Frey / GEZE GmbH
Automatic sliding door Powerdrive PL EI30, Athletics center Oym, Switzerland
Automatic sliding door system for fire protection doors with resistance class EI30 © Lorenz Frey / GEZE GmbH
ECDrive T2 FR
© Lorenz Frey / GEZE GmbH
Hôtel Richer de Belleval Montpellier
Reception hall: ECdrive T2 single leaf © Samuel Duplaix / GEZE GmbH
Slimdrive SL NT + GC 363 + LED sensor button, East Office
Automatic linear sliding door system with low height and clear design line, very smooth-running low-wear drive. © GEZE GmbH
ECdrive T2-FR automatic sliding door drive, installed in the Aldi Süd branch in Mühldorf
Automatic linear sliding door system for escape and rescue routes © Robert Sprang / GEZE GmbH
Automtic sliding door drive ECdrive T2-FR, Aldi Süd - Store in Muehldorf
Automatic linear sliding door system in escape and rescue routes © Robert Sprang / GEZE GmbH
Automtic sliding door drive ECdrive T2-FR, Aldi Süd - Store in Muehldorf
Automatic linear sliding door system in escape and rescue routes © Robert Sprang / GEZE GmbH
ECdrive T2-FR automatic sliding door drive
Automatic linear sliding door system for escape and rescue routes © Robert Sprang / GEZE GmbH
ECdrive sliding door system at Children's memorial Health Institute, Warsaw, Poland
Automatic linear sliding door system for areas with increased hygiene demands © H. Łukasz Janicki / GEZE Polska
TSA 160 NT in a operating room with hermetic-sealing doors at Children's Memorial Health Institute
Electrohydraulic swing door drive for single leaf doors with automatic reversing and Push & Go function triggers the automatic drive after light manual pressure on the door leaf. © H. Łukasz Janicki / GEZE Polska
Combined detectors GC 363 R im Children's Memorial Health Institute, Warsaw, Poland
Combined detectors for the activation and protection of automatic sliding doors with ten configurable lighting curtain configurations © H. Łukasz Janicki / GEZE Polska
Powerdrive HT sliding door drive system at Children's memorial health institute
Hermetically sealing sliding door systems with Powerdrive HT drives for large and heavy door leaves © H. Łukasz Janicki / GEZE Polska
Slimdrive SL NT + GC 363 + LED sensor button
Installation situation Slimdrive SL NT + GC 363 + LED sensor button. © GEZE GmbH
Technical data
| GC 363 | |
| Dimensions | 270 x 58 x 58 mm |
| Technology | Electromagnetic radar waves/active infrared beams |
| Number of active infrared detectors | 2 |
| Operating current | 125 mA |
| Output | Potential-free relay contact |
| IP rating | IP54 |
| Cable connection type | System plug-type connector |
| Connection cable length | 2600 mm |
| Installation height (min.) | 2000 mm |
| Installation height (max.) | 3500 mm |
| Weight | 250 g |
| Service temperature | -25 - 55 °C |
| Humidity | 0-95 % relative, non-condensing |
| Standard conformity | DIN 18650, EN 16005 |
