Radar movement detectors

GC 308 Radar movement detector with individual adjustment option for activating automatic doors

GC 308 black Radar movement detector
  • Individual settings for challenging environmental conditions
  • Configuration possible via push buttons or remote control
  • Compact dimensions, suitable for 7 cm profile heights
  • Integrated motion tracking also records slow movements
  • Movement direction detection and cross-traffic fade-out reduces energy consumption in the building
  • Door opening impulse only triggered if needed
Contact us

Radar movement detector with individual adjustment option for activating automatic doors

Application Areas

  • Activation of automatic swing and revolving doors
  • Interior and exterior doors

Technical data

GC 308
Dimensions 120 x 50 x 50 mm
Technology Electromagnetic radar waves
operating voltage 12-24 V DC +30% /-10% / 12-24 V AC ± 10%
Operating current 100 mA
Output Potential-free relay contact
IP rating IP54
Cable connection type System plug-type connector
Connection cable length 2500 mm
Installation height (min.) 1800 mm
Installation height (max.) 4000 mm
Transmission frequency 24.15 GHz
Weight 120 g
Service temperature -20 - 55 °C
Approvals RED 2014/53/EU, RoHS 2011/65/EU
