MSW with fine-framed panels

MSW sliding swing door with stop function - fine-framed * Access element for closed glass partitioning walls

MSW system with fine-framed leaves, Lazienki Kolo Wisly (Public WC in Warsaw) Manual sliding wall systems (MSW) open up, divide, and separate rooms and they adapt flexibly to your particular needs. With the MSW SmartGuide technology, shop fronts can be opened completely and no longer require swing door end panels.
  • Horizontal and vertical profiles for glass framing
  • Toughened safety glass ESG 10 mm flush on one side
  • Insulating glass 22 mm centred applicable
  • Element weight up to 125 kg
  • Integrated locking facility (Boxer 2-4V)
  • Dry glazing by means of circumferential glazing gasket
Show more
  • Can be combined with all other element types - fine-framed
Contact us

Application Areas

  • Internal and protected external area
  • Freely selectable position in the system front
  • Can be used up to 3000 mm clear height
  • Can be used up to 1100 mm element width
